FEATURES
w A small compact cabinet for flexible placement.
w Economical standard installation, easy to enjoy the convenience of 3D Technology.
w Without rims compensation, dynamic measurement
w To read the basic parameters within 1.5 minutes
w To add extensive functions on basis of traditional basic parameters.
SPECIFICATION VIEW
| Measurement Project | Accuracy | Measurement Range |
|---|---|---|
| Display accuracy | 1'/0.01°/0.1mm | |
| Camber | ± 2' | ± 10° |
| Caster | ± 6' | ± 20° |
| Kingpin inclination | ± 6' | ± 23° |
| Toe in & Toe out | ± 2' | ± 20° |
| Set back | ± 2' | ± 5° |
| Thrust angle | ± 2' | ± 5° |
| Wheel deviation | ± 2mm | |
| Axis deviation | ± 2mm | |
