FEATURES
· Compact and light weight, ideal for space restricted installations.
· Wall or ceiling mount.
· Reels come complete with PVC inlet hose, ball stop and complete mounting hardware.
· Redesigned steel ratchet and gears for long life.
· Solid brass axel.
SPECIFICATION VIEW
| Model | Hose | Maximum Working Pressure (MPa) | Inlet Hose | Dimensions (mm) | Body Weight (kg) | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Hose materials | Connection | Inner Diameter (mm) | Length (m) | Connection | Length (m) | A | B | C | |||
| SWR-310 | PVC | Female Rc3/8 | 8.0 | 10.0 | 0.5 | Male R3/8 | 1.0 | 408 | 384 | 173 | 6.4 |
