FEATURES
· Homologated and certified product according to the European Directive EN1493:1998+A1:2008.
· Mobile type, handled by the power pack cart.
· Hydraulic synchronization with assistant of bolster bar to avoid unexpected uneven of platforms.
· Mechanical safeties with air-operated release.
· Automatic stop at the maximum lifting height to protect the lift from over-height lifting.
· Overload valve equipped.
· Manual emergency lowering.
· "Dead man" operation by 24V push button.
· Free maintenance self-lubricating bushings.
SPECIFICATION VIEW
| Lifting capacity | 3000 kg |
| Max. Lifting Height | 960 mm |
| Min. Height | 100 mm |
| Platform Length | 1450 - 1984 mm |
| Platform Width | 530 mm |
| Lifting Time | 21 sec |
| Lowering Time | 18 sec |
| Electric Power | 220V / 380V |
| Motor Power | 2.2 kW |
| Weight | 550 kg |
