FEATURES
AUTOMATIC ARM RESTRAINT
• Provides easy positioning of arms up to 200 mm height.
• When the lift is raised over 200 mm, arm restraint automatically engage.
1 LEVER CONTROL
• 1 lever operates safely for both hook releasing and lowering.
ROLLING EASY ARMS
• Rollers mounted in Swing Arms provide easy and smooth setting of lifting point.
HYDRAULIC CYLINDER
• Dual hydraulic cylinder system has automatic shut off valve for protection against hydraulic failure.
SPECIFICATION VIEW
Lifting capacity | 4000 kg |
Overall height | 3913 mm |
Overall width (incl Hyd. unit) | 3210 mm |
Overall width (Base outside to Bas outside) |
3110 mm |
Overall length | 1200 mm |
Inside columns | 2500 mm |
Vertical travel | 1800 mm |
Max height of pad | 1970 mm |
Min height of pad |
125 mm |
Lifting time to max height | 64 sec. |
