FEATURES
w Self researching software, updating for free.
w No calibration required after assembled.
w Platform level different can be around 5mm, the alignment result will not be affected.
w Selection of 2 database. (Database from Shanghai Supplier in China and AUTODATA from United Kingdom.
SPECIFICATION VIEW
| Measurement Project | Accuracy | Measurement Range |
|---|---|---|
| Display accuracy | 1'/0.1mm | 1'/0.1mm |
| Camber | ± 2' | ± 10° |
| Caster | ± 6' | ± 20° |
| Kingpin inclination | ± 6' | ± 20 |
| Toe in & Toe out | ± 2' | ± 20° |
| Set back | ± 2' | ± 5° |
| Thrust angle | ± 2' | ± 5° |
| Wheel deviation | ± 2mm | |
| Axis deviation | ± 2mm |
