FEATURES
w User friendly
w High-Resolution Light Target
w Drive on assistant : Your assistant to drive on the lift
w High Quality camera - measure in "difference"
w New integrated lift with wormgear and safety system (Patent Pending)
SPECIFICATION VIEW
| Measuring Ranges | |
| Total toe | ± 20° |
| Half toe | ± 10° |
| Camber | ± 10° |
| Caster | ± 30° |
| King pin | ± 30° |
| Set back | ± 22° |
| Thrust angle | ± 10° |
| Steering difference | ± 20° |
| Power Supply | |
| Power Supply Voltage | 115-230 Vac / 50-60 Hz 1ph |
| Power Absorption | 500W |
| PC Holder | 11 kg |
| Camera Beam | 26 kg |
| Column | 66 kg |
| Camera Resolution | 2592 × 1944 10,000,000 Pixel |
